Luogo di origine: | Cina |
---|---|
Marca: | Taizhou KAD Electromechanical Co., Ltd. |
Certificazione: | CE |
Numero di modello: | ME900-1 |
Quantità di ordine minimo: | 1 unità |
Prezzo: | $800-$1000/unit |
Imballaggi particolari: | pallet di ferro e pellicola di plastica |
Tempi di consegna: | 15 giorni |
Termini di pagamento: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Capacità di alimentazione: | 50 unità |
Carico utile: | 130 kg | Altezza massima di lavoro: | 4-10m |
---|---|---|---|
Altezza massima della piattaforma: | 9 m | Distanze: | 1.34m |
Larghezza: | 0.85 | Altezza: | 2 metri |
Dimensione della piattaforma: | 00,60*0,55 m | Impronta dell'outrigger: | 1.70*1.67 |
Peso ((AC): | 370kg | ||
Evidenziare: | 9m Portable Lifter,10m Portable Lifter,8m Portable Lifter |
Multiple Height Options:
Available in various lifting heights (10m to 6m), users can select the right model based on their operational needs, whether for high shelving, elevated platforms, or maintenance work.
Lightweight & Portable:
Designed for easy transport and setup, the lifter can be moved by a single operator. Its compact frame fits through standard doorways and elevators, making it suitable for indoor and outdoor use.
Stable and Durable Structure:
Constructed with high-strength aluminum alloy or steel (depending on model), the lifter ensures maximum safety and long-term durability, even under frequent use.
Easy Operation:
With simple control buttons and safety mechanisms, operators can quickly raise and lower the platform with minimal training required.
Wide Range of Applications:
Perfect for logistics centers, electrical installations, building maintenance, and equipment handling in tight or elevated areas.
Model | ME600-1 | ME800-1 | ME900-1 | ME1000-1 | ||
Lift capacity | kg | 130 | 130 | 130 | 130 | |
Platform occupancy max | 1 | 1 | 1 | 1 | ||
Working height max | m | 8 | 10 | 11 | 12 | |
Platform height max | m | 6 | 8 | 9 | 10 | |
Stowed length | m | 1.34 | 1.34 | 1.45 | 1.45 | |
Stowed width | m | 0.85 | 0.85 | 0.85 | 0.85 | |
Stowed height | m | 2 | 2 | 2 | 2 | |
Platform size | m | 0.60*0.55 | 0.60*0.55 | 0.60*0.55 | 0.60*0.55 | |
Outrigger Footprint | m | 1.70*1.67 | 1.70*1.67 | 1.93*1.77 | 1.93*1.77 | |
Ground clearance | m | 0.05 | 0.05 | 0.55 | 0.05 | |
Lifting motor(AC) | kw | 0.75 | 0.75 | 0.75 | 0.75 | |
Weight(AC) | kg | 370 | 390 | 400 | 420 | |
Optional Configurations |
Power source | V/ah | 24/80 | 24/80 | 24/80 | 24/80 |
Lifting motor(DC) | kw | 0.8 | 0.8 | 0.8 | 0.8 | |
Charger | V/ah | 24/15 | 24/15 | 24/15 | 24/15 |
Time-Saving: Quickly set up and lift materials or personnel, reducing manual labor and boosting productivity.
Space-Efficient: Slim profile and folding arms make storage and transportation hassle-free.
Cost-Effective: Durable design and multipurpose functionality provide long-term value with low maintenance needs.
Safety Checks: Ensure ground conditions are stable and all safety locks are engaged before operation.
Weight Limit Compliance: Do not exceed the rated load capacity for each model height.
Regular Maintenance: Keep moving parts clean and check for any wear on lifting cables and wheels.
